My Part Number:
Part Number: T0-2-1/V/SVB-SW
Manufacturer Code: 045992
Multiples of: 1 | Minimum Order: 1
A 3-pole main switch and switch disconnector rated for 20 A. Designed for rear mounting, it features a highly visible black rotary handle with a locking ring, and is typically used for machine maintenance, emergency stopping, and manual isolation of industrial loads.
Core Specifications:
• Number of Poles: 3
• Maximum Continuous Current (Iu): 20 A
• Rated Operational Power: 6.5 kW (at 400 V)
• IP Rating: IP65
Key Features:
• Lockable: Can be locked in the 0 (Off) position to prevent unauthorized or accidental operation.
• STOP Function: Equipped with a built-in emergency switching off/stop function.
• Robust Design: Direct manual operation of contacts ensures positive opening, enhancing safety during maintenance.
• Mounting: Rear panel mounting with a 90° switching angle.
Physical Characteristics:
• Height: 74 mm
• Width: 65 mm
• Depth (including handle): 128 mm
Brand |
EATON MOELLER ELECTRIC |
|
