My Part Number:
Part Number: EX705-U5PY
Manufacturer Code: +EX705U5PY
Multiples of: 1 | Minimum Order: 1
The industrial HMI eX705 is the ultimate all-in-one solution ready for scalable applications across many industries.
This industrial automation device offer super high performance, high resolution glass PCAP touch, fully connectable upstream and downstream, powerful integrated PLC with all the major protocols, Integrated VPN with service cloud.
Brand |
EXOR INTERNATIONAL |
|
Colour Depth |
64 K |
|
CPU |
32-bit Quad Core - 800 MHz |
|
Operating System |
Linux |
|
RAM |
512 MB |
|
Screen Brightness |
300 cd/m² typical |
|
Storage |
4 GB |
|
Mounting Style |
Panel Mount |
|
Application |
Indoor |
|
Screen Size |
5" (inches) |
|
Resolution |
800 x 480 |
|
Display Type |
Capacitive |
|
Optional Features |
CODESYS |
|
Connectivity |
Ethernet Port x 2, Expansion Module x 1, SD Card, Serial Port x 1, USB Port x 1 |
|
Electrical Connection |
24 V DC Power Connector |
|
Height |
107 mm |
|
Width |
147 mm |
|
Depth |
52+8 mm |
|
Weight |
1.3 kg |
|
IP Rating |
IP66 |
|
Body Material |
Aluminium |
|
Minimum Operating Temperature |
-20 °C |
|
Maximum Operating Temperature |
60 °C |
Hazardous Area Certification |
Zone 2, Zone 22 |
|
Approvals |
NEC, CE, IECEx, UL - Canada & US, RCM, DNV |
Environment |
Indoor |
|
£739.71
per 1 (ex. VAT)£887.65
per 1 (inc. VAT)
