My Part Number:
Part Number: EX715MG-U5P1
Manufacturer Code: +EX715MGU5P1
Multiples of: 1 | Minimum Order: 1
eX715MG Web
eX715MG Web HMI combine high-performance sunlight-readable display with state-of-the-art connectivity features, high-power CPU and top browsing performance in a great design.
It is designed to be used in harsh environments where the safety of operators is at risk.
eX715MG is the ideal choice for all demanding IIoT edge applications in extreme environments such as marine and process industries where powerful and performing HTML5 web browser is needed.
The glass projected capacitive touchscreen and the brilliant 15 inch widescreen display with a resolution of 1920x1080 are bonded to guarantee the highest optical performance and resistance in such environments.
This product includes a Chromium based HTML5 browser with easy to use browser setting facilities.
Supports Corvina Cloud secure connectivity.
Brand |
EXOR INTERNATIONAL |
|
Colour Depth |
16 Million |
|
CPU |
64-bit Quad Core - 1.6 GHz |
|
Operating System |
Linux |
|
RAM |
1 GB |
|
Screen Brightness |
700 cd/m² typical |
|
Storage |
4 GB |
|
Mounting Style |
Panel Mount |
|
Application |
Outdoor |
|
Screen Size |
15" (inches) |
|
Resolution |
1920 x 1080 |
|
Display Type |
Capacitive - Optically Bonded |
|
Optional Features |
CODESYS |
|
Connectivity |
Buzzer x 1, Ethernet Port x 3, Expansion Modules x 2, SD Card, Serial Port x 1, USB Port x 2 |
|
Electrical Connection |
24 V DC Power Connector |
|
Height |
267 mm |
|
Width |
422 mm |
|
Depth |
56+8 mm |
|
Weight |
4.1 kg |
|
IP Rating |
IP66 |
|
Body Material |
Aluminium |
|
Minimum Operating Temperature |
-30 °C |
|
Maximum Operating Temperature |
70 °C |
Approvals |
NEC, CE, IECEx, UL - Canada & US, RCM, DNV |
£2,858.90
per 1 (ex. VAT)£3,430.68
per 1 (inc. VAT)
