My Part Number:
Part Number: RSC30/9
Manufacturer Code: 11581
Multiples of: 1 | Minimum Order: 1
7/8" Power Field Attachable Connector: Male, straight, 3-pin(2+PE), black housing, 230 V AC/DC, 12 A
Brand |
LUMBERG AUTOMATION |
|
IP Rating |
IP67 |
|
Approvals |
CE, RoHS |
Terminal Connection |
Screw |
|
Additional Information |
Connector Material: TPU |
|
Connection Method |
Coupling Screw With External Threads |
|
Connection Method B |
Gland Entry |
|
Connection Type |
Field Attachable |
|
Connection Size |
7/8'' |
|
Number Of Pins |
3 - Three Pin |
|
Connection Gender |
Male |
|
Connection Orientation |
Straight |
|
Connection Size B |
Pg9 |
|
Voltage Rating |
230 V AC |
|
Current Rating |
12 A |
|
Additional Features |
Shielded: No |
|
Minimum Ambient Temperature |
-40 °C |
|
Maximum Ambient Temperature |
90 °C |
£15.50
per 1 (ex. VAT)£18.60
per 1 (inc. VAT)7/8" Power Field Attachable Connector: Male, straight, 3-pin(2+PE), black housing, 230 V AC/DC, 12 A
