My Part Number:
Part Number: POWTOC16/14501
Manufacturer Code: 14501
Multiples of: 1 | Minimum Order: 1
Connector PowerTOP® Xtra with ErgoCONTACT 14501
All versions of the PowerTOP® Xtra connector deliver excellent results thanks to their ergonomic design, easy to install, safe and easy connection, and X-CONTACT® inside. The innovative contact sleeves ensure easy insertion and withdrawal. The PowerTOP® Xtra connector has IP 54 protection class and is therefore impervious to both water spray and dust.
• screw connection technology ErgoCONTACT
• X-CONTACT®
• ergonomic enclosure design with nubbed grip zones
• rubberised cable gland with sealing
• strain relief and protection against kinking
• thread lock and safety slide
• area for self-adhesive labels
Technical specifications
Ampere: 16 A
Poles: 3 p
Voltage: 110 V
Clock position: 4 h
Hertz: 50-60 Hz
Connection technology: Screw terminals, ErgoCONTACT®
Contact: X-CONTACT
Protection type: IP54
Weight: 200 g
Certifications: CB Zertifikat, VDE
Brand |
MENNEKES |
|
£11.21
per 1 (ex. VAT)£13.45
per 1 (inc. VAT)
