My Part Number:
Part Number: CBN15-F64-A2
Manufacturer Code: 263265
Multiples of: 1 | Minimum Order: 1
A flat-housing, rectangular capacitive proximity sensor designed for non-flush industrial automation. It features an adjustable 15 mm rated operating distance and a complementary PNP output type (both Normally Open and Normally Closed).
Key Technical Specifications:
• Sensing Range: 15 mm, with an adjustable switching distance between 2 mm and 15 mm.
• Output Configuration: PNP, 4-wire, complementary (1 x NO + 1 x NC).
• Operating Voltage: 10 to 30 V DC.
• Housing Material: Polybutylene Terephthalate (PBT).
• Ingress Protection: IP67 rated against water and dust.
• Connection Type: Pre-wired 2-metre PUR cable.
• Switching Frequency: 0 to 100 Hz.
• Indicators: Yellow LED for switching state visualisation.
• Electrical Safety: Reverse polarity and short-circuit protection.
Core Benefits & Design Features:
• Flat Housing: The thin, rectangular form factor makes it ideal for tight spaces where cylindrical sensors cannot fit.
• Adjustable Sensitivity: The built-in sensitivity adjuster allows users to tune the sensing threshold precisely for different materials or fluid level detection through container walls.
• Industrial Durability: Highly resilient PBT housing paired with an IP67 rating ensures steady operation in harsh, wet, or dusty factory conditions.
Brand |
PEPPERL & FUCHS |
|
£100.59
per 1 (ex. VAT)£120.71
per 1 (inc. VAT)
