My Part Number:
Part Number: NBN8-18GM50-A0-V1
Manufacturer Code: 326161-0127
Multiples of: 1 | Minimum Order: 1
A miniature photoelectric triangulation sensor (diffuse mode with background suppression) with a laser light source, commonly used in industrial automation.
It offers a detection range of 7 to 250 mm and features an IO-Link interface for data communication.
Key Benefits:
• 8 mm non-flush
• Extended temperature range -40 - +85 °C
• Extended operating voltage range
• Flexible use with versatile mounting opportunities
• Extremely high switching frequency
General specifications
Switching function: complementary
Output type: NPN
Rated operating distance sn: 8 mm
Installation: non-flush
Output polarity: DC
Assured operating distance sa: 0 ... 6.48 mm
Actuating element: mild steel, e. g. 1.0037, SR235JR (formerly St37-2) 24 mm x 24 mm x 1 mm
Reduction factor rAl: 0.44
Reduction factor rCu: 0.42
Reduction factor r304: 0.76
Reduction factor rBrass: 0.52
Output type: 4-wire
Brand |
PEPPERL & FUCHS |
|
£67.25
per 1 (ex. VAT)£80.70
per 1 (inc. VAT)
