My Part Number:
Part Number: OBE20M-R100-S2EP-IOL
Manufacturer Code: 281003
Multiples of: 1 | Minimum Order: 1
Thru-beam sensor (pair)
• Miniature design with versatile mounting options
• DuraBeam Laser Sensors - durable and employable like an LED
• IO-Link interface for service and process data
• Various frequencies for avoiding mutual interference (cross-talk immunity)
• Extended temperature range -40 °C ... 60 °C
• High degree of protection IP69K
Effective detection range: 0 ... 20 m
Threshold detection range: 30 m
Light source: laser diode
Light type: modulated visible red light
Laser nominal ratings
Note: LASER LIGHT , DO NOT STARE INTO BEAM
Laser class: 1
Wave length: 680 nm
Beam divergence: > 5 mrad ; d63 < 2 mm in the range of 250 mm ... 750 mm
Pulse length: 1.6 µs
Repetition rate: max. 17.6 kHz
max. pulse energy: 9.6 nJ
Diameter of the light spot: approx. 50 mm at a distance of 20 m
Opening angle: approx. 0.3 °
Ambient light limit: EN 60947-5-2 : 30000 Lux
Brand |
PEPPERL & FUCHS |
|
£139.89
per 1 (ex. VAT)£167.87
per 1 (inc. VAT)
