My Part Number:
Part Number: OBT250-R1032EPIOV31L
Manufacturer Code: 267075-100322 / OBT250-R103-2EP-IO-V31-L
Multiples of: 1 | Minimum Order: 1
A miniature photoelectric triangulation sensor (diffuse mode with background suppression) with a laser light source, commonly used in industrial automation.
It offers a detection range of 7 to 250 mm and features an IO-Link interface for data communication.
Key Features
• According to information from Pepperl+Fuchs and various merchants, the key specifications of the OBT250-R103-2EP-IO-V31-L are as follows:
• Detection Range: 7 to 250 mm.
• Light Source: Laser diode, modulated visible red light (Laser Class 1).
• Signal Output: 2 push-pull (4-in-1) outputs, short-circuit, reverse polarity, and overvoltage protected.
• Interface Type: IO-Link via C/Q = pin 4.
• Connection: M8 x 1 connector, 4-pin.
• Operating Voltage: 10 to 30 V DC.
• Ambient Temperature: -40 °C to 60 °C (-40 °F to 140 °F).
• Protection Rating: High degree of protection at IP67 and IP69K, ensuring reliability in demanding environments.
• Material: The housing is made of PC and the optical face is PMMA.
Brand |
PEPPERL & FUCHS |
|
£153.28
per 1 (ex. VAT)£183.94
per 1 (inc. VAT)
