My Part Number:
Part Number: UB2000-F42S-E5-V15
Manufacturer Code: 133994
Multiples of: 1 | Minimum Order: 1
A high-performance, compact industrial ultrasonic proximity sensor. It uses a single-head diffuse system to deliver precise, non-contact distance measurements. It works reliably regardless of an object's colour, gloss, or surface texture.
Technical Specifications:
• Sensing Range: 60 mm to 2000 mm
• Operating Voltage: 10 V DC to 30 V DC
• Output Type: Configurable PNP switching output (selectable Normally Open / Normally Closed)
• Connection: 5-pin, M12 x 1 device connector
• Housing Material: Robust ABS plastic
• Ingress Protection: IP54 rated
• Transducer Frequency: 175 kHz
• Operating Temperature: -25 °C to 70 °C
Key Features:
• Minimal Blind Zone: Features an extremely small unusable area in the close range.
• TEACH-IN Programming: Simplifies sensor configuration and evaluation limits via built-in buttons.
• Interference Suppression: Offers adjustable divergence of the sound cone to prevent false triggers from surrounding obstructions.
• Temperature Compensation: Automatically adjusts for temperature changes to maintain measurement accuracy.
• Synchronisation Options: Allows multiple sensors to operate near each other without mutual interference.
Common Applications:
• Conveyor Systems: Reliable object detection and material flow tracking.
• Mechanical Engineering: General position tracking and automation.
• Container Inspection: High-accuracy level monitoring and container verification.
Brand |
PEPPERL & FUCHS |
|
£227.94
per 1 (ex. VAT)£273.53
per 1 (inc. VAT)
