My Part Number:
Part Number: UC500-30GM70S-UE2R2-
Manufacturer Code: 238399 / UC500-30GM70S-UE2R2-V15
Multiples of: 1 | Minimum Order: 1
Ultrasonic diffuse sensor with pivoting transducer
Key Benefits at a Glance
• Analog output 0 ... 10 V
• 1 switch output
• Synchronization options
• Temperature compensation
• Can be parameterized via the ULTRA-PROG-IR software and interface (accessories)
Sensing range: 45 ... 500 mm
Adjustment range: 50 ... 500 mm
Dead band: 0 ... 45 mm
Standard target plate: 100 mm x 100 mm
Transducer frequency: approx. 300 kHz
Response delay: ≤ 60 ms
Brand |
PEPPERL & FUCHS |
|
£359.07
per 1 (ex. VAT)£430.88
per 1 (inc. VAT)
Ultrasonic diffuse sensor with pivoting transducer
Key Benefits at a Glance
• Analog output 0 ... 10 V
• 1 switch output
• Synchronization options
• Temperature compensation
• Can be parameterized via the ULTRA-PROG-IR software and interface (accessories)
Sensing range: 45 ... 500 mm
Adjustment range: 50 ... 500 mm
Dead band: 0 ... 45 mm
Standard target plate: 100 mm x 100 mm
Transducer frequency: approx. 300 kHz
Response delay: ≤ 60 ms
Brand |
PEPPERL & FUCHS |
|
