My Part Number:
Part Number: 0708739
Manufacturer Code: HDFK 50
Multiples of: 1 | Minimum Order: 1
Panel feed-through terminal block
Easy grouping with engagement pin versions
Both terminal halves can be easily assembled by simply snapping them together
Touch-proof insulating housing in a new design
Universal screw connection with screw locking
Spacer plates increase clearances and creepage distances
Automatic compensation of the panel thickness via the snap principle integrated in the insulation housing
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Tool-free snap-in principle enables easy mounting on the device panel
Automatic panel thickness compensation enables universal use
Connection method: Screw connection
Number of positions: 1
Load current: 150 A
Cross section: 16 mm² - 50 mm²
AWG: 6 - 1/0
Connection direction of the conductor to plug-in direction: 0 °
Width: 18.8 mm
Colour: grey
Brand |
PHOENIX CONTACT |
|
£8.74
per 1 (ex. VAT)£10.49
per 1 (inc. VAT)
