My Part Number:
Part Number: 1733570
Manufacturer Code: SMKDSP 1,5/ 2-5,08
Multiples of: 250 | Minimum Order: 250
PCB terminal block
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Allows connection of two conductors
Angled connection enables multi-row arrangement on the PCB
Quick and convenient testing using integrated test option
The latching on the side enables various numbers of positions to be combined
Nominal current: 17.5 A
Pitch: 5.08 mm
Number of positions: 2
Connection method: Screw connection with tension sleeve
Mounting: Wave soldering
Conductor/PCB connection direction: 55 °
Colour: green
Brand |
PHOENIX CONTACT |
|
£0.79
per 1 (ex. VAT)£0.95
per 1 (inc. VAT)
