My Part Number:
Part Number: 1759114
Manufacturer Code: MSTB 2,5/12-G-5,08
Multiples of: 50 | Minimum Order: 50
PCB headers
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Easy PCB replacement thanks to plug-in modules
Well-known mounting principle allows worldwide use
Plug-in direction parallel to the PCB
Items that can be aligned in various pitches support flexible and space-saving PCB assembly
Nominal current: 12 A
Number of positions: 12
Pitch: 5.08 mm
Contact surface: Tin
Mounting: Wave soldering
Colour: green
Brand |
PHOENIX CONTACT |
|
£2.62
per 1 (ex. VAT)£3.14
per 1 (inc. VAT)
PCB headers
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Easy PCB replacement thanks to plug-in modules
Well-known mounting principle allows worldwide use
Plug-in direction parallel to the PCB
Items that can be aligned in various pitches support flexible and space-saving PCB assembly
Nominal current: 12 A
Number of positions: 12
Pitch: 5.08 mm
Contact surface: Tin
Mounting: Wave soldering
Colour: green
Brand |
PHOENIX CONTACT |
|
