My Part Number:
Part Number: 1777989
Manufacturer Code: MSTB2,5/2-ST-F-S,08
Multiples of: 100 | Minimum Order: 100
PCB connector - MSTB 2,5/ 2-STF-5,08
Nominal cross section: 2.5 mm2
Colour: green
Nominal current: 12 A
Rated voltage (III/2): 320 V
Contact surface: Tin
Type of contact: Female connector
Number of potentials: 2
Number of rows: 1
Number of positions: 2
Number of connections: 2
Product range: MSTB 2,5/..-STF
Pitch: 5.08 mm
Connection method: Screw connection with tension sleeve
Screw head form: L Slotted
Conductor/PCB connection direction: 0 °
Locking clip: - without locking clip
Plug-in system: COMBICON MSTB 2,5
Locking: Screw locking
Mounting: Screw flange
Brand |
PHOENIX CONTACT |
|
£1.26
per 1 (ex. VAT)£1.51
per 1 (inc. VAT)
