My Part Number:
Part Number: 1786417
Manufacturer Code: IC 2,5/ 3-G-5,08
Multiples of: 50 | Minimum Order: 50
PCB connector
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Easy PCB replacement thanks to plug-in modules
Well-known mounting principle allows worldwide use
Inverted header with socket contacts for touch-proof device outputs or PCB/PCB connections
Nominal current: 12 A
Pitch: 5.08 mm
Number of positions: 3
Connection method: Screw connection with tension sleeve
Contact surface: Tin
Colour: green
Brand |
PHOENIX CONTACT |
|
£1.49
per 1 (ex. VAT)£1.79
per 1 (inc. VAT)
