My Part Number:
Part Number: 1840447
Manufacturer Code: MC1,5/10-ST-3,5
Multiples of: 50 | Minimum Order: 50
PCB connector - MC 1,5/10-ST-3,5
Nominal cross section: 1.5 mm2
Colour: green
Nominal current: 8 A
Rated voltage (III/2): 160 V
Contact surface: Tin
Type of contact: Female connector
Number of potentials: 10
Number of rows: 1
Number of positions: 10
Number of connections: 10
Product range: MC 1,5/..-ST, pitch: 3.5 mm
Connection method: Screw connection with tension sleeve
Screw head form: L Slotted
Conductor/PCB connection direction: 0 °
Number of solder pins per potential: 1
Plug-in system: COMBICON MC 1,5
Locking: without
Mounting: without
Brand |
PHOENIX CONTACT |
|
£6.57
per 1 (ex. VAT)£7.88
per 1 (inc. VAT)
