My Part Number:
Part Number: 1840560
Manufacturer Code: DFK-PC 4/ 3-GF-7,62
Multiples of: 50 | Minimum Order: 50
Feed-through header
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Allows connection of two conductors
Screwable flange for superior mechanical stability
Flexible side panels enable convenient wall mounting prewired from the inside
Nominal current: 20 A
Number of positions: 3
Pitch: 7.62 mm
Connection method: Screw connection with tension sleeve
Contact surface: Tin
Mounting: Direct mounting
Colour: green
Brand |
PHOENIX CONTACT |
|
£3.94
per 1 (ex. VAT)£4.73
per 1 (inc. VAT)
