My Part Number:
Part Number: 1844294
Manufacturer Code: MC1,5/10-G-3,5
Multiples of: 100 | Minimum Order: 100
PCB header - MC 1,5/10-G-3,5
Nominal cross section: 1.5 mm2
Colour: green
Nominal current: 8 A
Rated voltage (III/2): 160 V
Contact surface: Tin
Type of contact: Male connector
Number of potentials: 10
Number of rows: 1
Number of positions: 10
Number of connections: 10
Product range: MC 1,5/..-G, pitch: 3.5 mm
Mounting: Wave soldering
Pin layout: Linear pinning
Solder pin [P]: 3.4 mm
Number of solder pins per potential: 1
Plug-in system: COMBICON MC 1,5
Pin connector pattern alignment: Standard
Locking: without
Mounting: without
Brand |
PHOENIX CONTACT |
|
£2.28
per 1 (ex. VAT)£2.74
per 1 (inc. VAT)
