My Part Number:
Part Number: 1923047
Manufacturer Code: UK 5-TWIN BU
Multiples of: 1 | Minimum Order: 1
1-level terminal block with double connection on one side
These twin modular terminal blocks are designed for the basic task of potential branching
Universal foot for mounting on NS 35.. or NS 32... DIN rails
Two independent conductor connections can be used on the control cabinet side
Easy connection of different types of conductors with different cross sections
Can be bridged in the terminal center, even with neighboring feed-through terminal blocks aligned
Cross section: 0.2 - 4 mm²
AWG: 24 - 12
Width: 6.2 mm
Colour: blue
Brand |
PHOENIX CONTACT |
|
£1.90
per 1 (ex. VAT)£2.28
per 1 (inc. VAT)
1-level terminal block with double connection on one side
These twin modular terminal blocks are designed for the basic task of potential branching
Universal foot for mounting on NS 35.. or NS 32... DIN rails
Two independent conductor connections can be used on the control cabinet side
Easy connection of different types of conductors with different cross sections
Can be bridged in the terminal center, even with neighboring feed-through terminal blocks aligned
Cross section: 0.2 - 4 mm²
AWG: 24 - 12
Width: 6.2 mm
Colour: blue
Brand |
PHOENIX CONTACT |
|
