My Part Number:
Part Number: 2313915
Manufacturer Code: FL ISOLATOR 1000-RJ/RJ
Multiples of: 1 | Minimum Order: 1
Passive network isolator
For electrical isolation in Ethernet networks. This protects Ethernet devices from potential differences of up to 4 kV. Can be used for transmission speeds of up to 1 Gbps. Possible to connect two RJ45 plugs.
The FL ISOLATOR is used for electrical isolation in copper-based Ethernet networks.
In industrial environments, potential differences pose a constant problem with regard to interference-free data transmission.
The high-quality isolation for up to 4 kV provides reliable protection for Ethernet devices and interfaces. This results in considerably higher immunity to interference in industrial applications.
No power supply required
Dielectric strength of up to 4 kV
Protection against aggressive environmental influences, particularly harsh industrial environments, thanks to coated PCB
Approval for railway applications (rolling stock) according to EN 50155 and EN 50121
Electrical isolation of data cables and cable shielding
Extended temperature range of -25°C to +85°C
Mounting on EN DIN rails
Transmission speed of up to 1000 Mbps
Continuous insulation voltage of 250 VRMS
Shipbuilding approval in accordance with DNV GL
Brand |
PHOENIX CONTACT |
|
£243.08
per 1 (ex. VAT)£291.70
per 1 (inc. VAT)
