My Part Number:
Part Number: 2701495
Manufacturer Code: AXL E EIP DI8 DO4 2A H12 6P
Multiples of: 1 | Minimum Order: 1
Axioline E, Digital I/O device, EtherNet/IP™, M12 fast connection technology, Plastic housing
Connection to EtherNet/IP™ network using M12connectors (D-coded)
Transmission speed of 10 Mbps and 100 Mbps
Connection of digital sensors and actuators using M12connectors (A-coded)
Diagnostic and status indicators
Short-circuit and overload protection of the sensor supply
IP65/IP67 degree of protection
Digital inputs: 8 , 24 V DC
Connection method: 4-wire
Digital outputs: 4, 24 V DC, 500 mA
Connection method: 3-wire
Degree of protection: IP65/IP67
Brand |
PHOENIX CONTACT |
|
£442.10
per 1 (ex. VAT)£530.52
per 1 (inc. VAT)
Axioline E, Digital I/O device, EtherNet/IP™, M12 fast connection technology, Plastic housing
Connection to EtherNet/IP™ network using M12connectors (D-coded)
Transmission speed of 10 Mbps and 100 Mbps
Connection of digital sensors and actuators using M12connectors (A-coded)
Diagnostic and status indicators
Short-circuit and overload protection of the sensor supply
IP65/IP67 degree of protection
Digital inputs: 8 , 24 V DC
Connection method: 4-wire
Digital outputs: 4, 24 V DC, 500 mA
Connection method: 3-wire
Degree of protection: IP65/IP67
Brand |
PHOENIX CONTACT |
|
