My Part Number:
Part Number: 2701524
Manufacturer Code: AXL E EC IOL8 DI4 M12 6P
Multiples of: 1 | Minimum Order: 1
Axioline E-EtherCAT® device in a plastic housing with 8 IO-Link ports and 4 digital inputs, 24 V DC, M12 fast connection technology
Connection to EtherCAT® network using M12connectors (D-coded)
Transmission speed of 100 Mbps
Connection of four IO-Link devices with additional digital input
Connection of four IO-Link actuators with additional power supply
Connection of IO-Link ports using M12connectors (A-coded, 5-pos.)
IO-Link specification V1.1.2
Diagnostic and status indicators
Short-circuit and overload protection of the sensor supply
IP65/IP67 degree of protection
Brand |
PHOENIX CONTACT |
|
£502.04
per 1 (ex. VAT)£602.45
per 1 (inc. VAT)
