My Part Number:
Part Number: 2861386
Manufacturer Code: IB IL TEMP 2 UTH-PAC
Multiples of: 1 | Minimum Order: 1
Inline, Temperature measurement terminal, including Inline connector and labeling field
The terminal is designed for use within an Inline station.
This terminal can be used to acquire signals from standard thermocouples.
It supports 13 different types of thermocouples according to DIN EN 60584-1 and DIN 43710, as well as a linear voltage input of -15 mV to +85 mV.
2 differential inputs for thermocouples or linear voltage
1 input for an external cold junction, Pt 1000 or Ni 1000
The channels are parameterized independently of one another via the bus system
Internal detection and compensation of cold junction temperature (can be parameterized)
Absolute and differential temperature measurement (can be parameterized)
Pt 1000 sensor in the vicinity of the connection terminal blocks of the thermocouple inputs for internal measurement of the cold junction
temperature
Measured values can be represented in three different formats
Analog UTH inputs: 2 (Thermocouples or linear voltage)
Connection method: 2-wire
Transmission speed in the local bus: 500 kbps
Degree of protection: IP20
Brand |
PHOENIX CONTACT |
|
£248.87
per 1 (ex. VAT)£298.64
per 1 (inc. VAT)
