My Part Number:
Part Number: 2865450
Manufacturer Code: MACX MCR-EX-SL-NAM-2RO(-SP)
Multiples of: 1 | Minimum Order: 1
Ex i NAMUR isolating amplifier For operating proximity sensors and switches in Ex areas. The signals are transmitted via 2 relay outputs (N/O contact) to the safe area. Line fault detection (LFD), 3-way isolation, SIL 2.
Power supply and error indication possible via DIN rail connector
Installation in zone 2, protection type "n" (EN 60079-15) permitted
Up to SIL 2 according to EN 61508
Line fault detection (LFD), can be activated/deactivated, error indicated by red flashing LED with de-excitation of output relay
4-way electrical isolation
Direction of operation can be selected (operating or closed circuit current behavior)
2 relay signal outputs (N/O contact); output 2 can also be used as an error signaling output
Input for NAMUR proximity sensors (EN 60947-5-6), floating contacts or contacts with resistance circuit, [Ex ia] IIC
LED indicators for supply voltage, switching state, and malfunction according to NAMUR NE 44
Brand |
PHOENIX CONTACT |
|
Output Type |
NAMUR |
|
£138.54
per 1 (ex. VAT)£166.25
per 1 (inc. VAT)
Ex i NAMUR isolating amplifier For operating proximity sensors and switches in Ex areas. The signals are transmitted via 2 relay outputs (N/O contact) to the safe area. Line fault detection (LFD), 3-way isolation, SIL 2.
Power supply and error indication possible via DIN rail connector
Installation in zone 2, protection type "n" (EN 60079-15) permitted
Up to SIL 2 according to EN 61508
Line fault detection (LFD), can be activated/deactivated, error indicated by red flashing LED with de-excitation of output relay
4-way electrical isolation
Direction of operation can be selected (operating or closed circuit current behavior)
2 relay signal outputs (N/O contact); output 2 can also be used as an error signaling output
Input for NAMUR proximity sensors (EN 60947-5-6), floating contacts or contacts with resistance circuit, [Ex ia] IIC
LED indicators for supply voltage, switching state, and malfunction according to NAMUR NE 44
Brand |
PHOENIX CONTACT |
|
Output Type |
NAMUR |
|
