My Part Number:
Part Number: 2865609
Manufacturer Code: MACX MCR-EX-SL-SD-24-48-LP
Multiples of: 1 | Minimum Order: 1
Ex i solenoid driver. For the intrinsically safe control of Ex i solenoid valves, alarm modules or LEDs installed in the Ex area. Current limitation at 48 mA. For gases up to Group IIC, loop-powered, electrical isolation, SIL 3. Screw connection.
Mechanically compatible with the DIN rail connector
Various output characteristic curves compatible with standard solenoid valves
Loop-powered: the required power is supplied via the control signal on the input side.
Installation in zone 2, protection type "n" (EN 60079-15) permitted
Up to SIL 3 according to IEC 61508
2-way electrical isolation
Input 19.2 ... 30 V DC
Output [Ex ia] IIC/[Ex ia] IIB
Brand |
PHOENIX CONTACT |
|
£146.17
per 1 (ex. VAT)£175.40
per 1 (inc. VAT)
