My Part Number:
Part Number: 2897211
Manufacturer Code: IL DN BK DI8 DO4-PAC
Multiples of: 1 | Minimum Order: 1
Inline, Bus coupler, DeviceNet™, TWIN COMBICON, including Inline connectors and marking fields
DeviceNet™ connection using TWIN-COMBICON plug
62 terminals can be connected
Automatic speed detection of the system bus
Address can be set via DIP switches or software
Slave function in DeviceNet™ network
Digital inputs: 8 , 24 V DC
Connection method: 3-wire
Digital outputs: 4, 24 V DC, 500 mA
Connection method: 3-wire
Transmission speed in the local bus: 500 kbps / 2 Mbps
Degree of protection: IP20
Brand |
PHOENIX CONTACT |
|
£318.28
per 1 (ex. VAT)£381.94
per 1 (inc. VAT)
