My Part Number:
Part Number: 2904375
Manufacturer Code: UNO-PS/1AC/5DC/40W
Multiples of: 1 | Minimum Order: 1
UNO-PS/1AC/ 5DC/ 40W - Power supply unit
Primary-switched UNO POWER power supply for DIN rail mounting, input: 1-phase, output: 5 V DC/40 W
UNO POWER power supplies with basic functionality
Thanks to their high power density, compact UNO POWER power supplies are the ideal solution for loads up to 240 W, particularly in compact control boxes. The power supply units are available in various performance classes and overall widths. Their high degree of efficiency and low idling losses ensure a high level of energy efficiency.
Product type: Power supply
Product family: UNO POWER
MTBF (IEC 61709, SN 29500): > 1201000 h (40 °C)
Insulation characteristics
Protection class: II (in closed control cabinet)
Degree of pollution: 2
Number of phases: 1.00
Insulation voltage input/output: 4 kV AC (type test), 3 kV AC (routine test)
Width: 35 mm
Height: 90 mm
Depth: 84 mm
Installation dimensions
Installation distance right/left: 0 mm / 0 mm
Installation distance top/bottom: 30 mm / 30 mm
Brand |
PHOENIX CONTACT |
|
