My Part Number:
Part Number: 2906058
Manufacturer Code: ELR-H5-IES-PT/24DC/500AC-06-7
Multiples of: 1 | Minimum Order: 1
ELR H5-IES-PT-24DC/500AC-06-T - Hybrid motor starter
Product type: Hybrid motor starters
Product family: CONTACTRON
Operating mode: 100% operating factor
Number of phases: 3
Motor starter type: Reversing starter
Maximum power dissipation for nominal condition: 0.4 W
Switching frequency: ≤ 2 Hz (Load-dependent)
Maximum power dissipation: 1.5 W
Minimum power dissipation: 1.1 W
Coordination type: 1
Supply
Rated control circuit supply voltage US: 24 V DC
Control supply voltage range: 19.2 V DC ... 30 V DC
Rated control supply current IS: 40 mA
Protective circuit: Surge protection, Reverse polarity protection
Insulation characteristics
Rated insulation voltage: 500 V
Rated surge voltage: 6 kV
Overvoltage category: III
Brand |
PHOENIX CONTACT |
|
£159.93
per 1 (ex. VAT)£191.92
per 1 (inc. VAT)
