My Part Number:
Part Number: 3047400
Manufacturer Code: UTME-6
Multiples of: 1 | Minimum Order: 1
UTME 6 - Test disconnect terminal block
Test disconnect terminal block, nom. voltage: 500 V, nominal current: 30 A, 1 level, connection method: Screw connection, Rated cross section: 6 mm2, cross section: 0.2 mm2 - 10 mm2, mounting: NS 35/7,5, NS 35/15, colour: gray
Product type: Test disconnect terminal block
Number of connections: 2
Number of rows: 1
Potentials: 1
Insulation characteristics
Overvoltage category: III
Degree of pollution: 3
Rated surge voltage: 6 kV
Maximum power dissipation for nominal condition: 1.31 W
Brand |
PHOENIX CONTACT |
|
£7.07
per 1 (ex. VAT)£8.48
per 1 (inc. VAT)
UTME 6 - Test disconnect terminal block
Test disconnect terminal block, nom. voltage: 500 V, nominal current: 30 A, 1 level, connection method: Screw connection, Rated cross section: 6 mm2, cross section: 0.2 mm2 - 10 mm2, mounting: NS 35/7,5, NS 35/15, colour: gray
Product type: Test disconnect terminal block
Number of connections: 2
Number of rows: 1
Potentials: 1
Insulation characteristics
Overvoltage category: III
Degree of pollution: 3
Rated surge voltage: 6 kV
Maximum power dissipation for nominal condition: 1.31 W
Brand |
PHOENIX CONTACT |
|
