My Part Number:
Part Number: 3073584
Manufacturer Code: RW 5
Multiples of: 1 | Minimum Order: 1
Panel feed-through terminal block
Quick and easy conductor connection thanks to hinged cover flaps with captive clamping nut
Both terminal halves can be easily assembled by simply snapping them together
Spring-loaded spacers protect the bolt connection against loosening
Touch-proof insulating housing in a new design
Automatic compensation of the panel thickness via the snap principle integrated in the insulation housing
Connection method: Bolt connection
Number of positions: 1
Load current: 76 A
Cross section: 0.1 mm² - 16 mm²
AWG: 26 - 6
Connection direction of the conductor to plug-in direction: 0 °
Width: 16.3 mm
Colour: grey
Brand |
PHOENIX CONTACT |
|
£7.38
per 1 (ex. VAT)£8.86
per 1 (inc. VAT)
Panel feed-through terminal block
Quick and easy conductor connection thanks to hinged cover flaps with captive clamping nut
Both terminal halves can be easily assembled by simply snapping them together
Spring-loaded spacers protect the bolt connection against loosening
Touch-proof insulating housing in a new design
Automatic compensation of the panel thickness via the snap principle integrated in the insulation housing
Connection method: Bolt connection
Number of positions: 1
Load current: 76 A
Cross section: 0.1 mm² - 16 mm²
AWG: 26 - 6
Connection direction of the conductor to plug-in direction: 0 °
Width: 16.3 mm
Colour: grey
Brand |
PHOENIX CONTACT |
|
