My Part Number:
Part Number: 3214495
Manufacturer Code: PTTBS 1,5/S/2P
Multiples of: 1 | Minimum Order: 1
PTTBS 1,5/S/2P - Double-level terminal block
Double-level terminal block, Current and voltage are determined by the plug used., nom. voltage: 500 V, nominal current: 16 A, connection method: Push-in / plug connection, 1st and 2nd level, Rated cross section: 1.5 mm2, cross section: 0.14 mm2 - 1.5 mm2, mounting type: NS 35/7,5, NS 35/15, colour: gray
Product type: Plug-in terminal block
Number of connections: 4
Number of rows: 2
Potentials: 2
Insulation characteristics
Overvoltage category: III
Brand |
PHOENIX CONTACT |
|
£2.28
per 1 (ex. VAT)£2.74
per 1 (inc. VAT)
