My Part Number:
Part Number: CS06020.1-00
Manufacturer Code: 06020.1-00
Multiples of: 1 | Minimum Order: 1
ENCLOSURE HEATER
CS 060 | 150 W
This is a compact enclosure heater with PTC heating element for guaranteed protection against condensation inside control cabinets and enclosures. The convection heater is safe to touch thanks to its plastic casing, protecting users from heat exposure. This heater is also available as a series with pre-set thermostat (tamper-proof thermostat): CSF 060
• Safe to touch, low surface temperature
• Quick to mount onto DIN rail 35 mm
• This enclosure heater is designed for long-term use
• PTC heating element
Operating voltage: AC/DC 120 - 240 V¹ (min. 110 V, max. 265 V)
Heating element: PTC resistor - temperature limiting
Surface temperature: < +80°C (+176°F), except upper protective grille
Connection: 4-pole terminal 2.5mm², torque 0.8 Nm max.
Casing: plastic according to UL94 V-0, black
Mounting: clip for 35mm DIN rail, EN 60715
Fitting position: vertical airflow (air outlet up, connection on bottom)
Operating/Storage temperature: -45 to +70 °C (-49 to +158 °F)
Operating/Storage humidity: < 90% RH (non-condensing)
Protection type/Protection class: IP20 / II (double insulated)
Approvals: VDE, UL File No. E150057, EAC
Brand |
STEGO |
|
£74.56
per 1 (ex. VAT)£89.47
per 1 (inc. VAT)
