My Part Number:
Part Number: HGK04702.0-00
Manufacturer Code: 04702.0-00
Multiples of: 1 | Minimum Order: 1
ENCLOSURE HEATER
HGK 047 | 30 W
This compact enclosure heater with a PTC heating element prevents condensation in control cabinets. It is a convection heater for small control cabinets and enclosures. The heater body has an anodised aluminium profile.
• Wider range of voltages for electrical connection
• PTC heating element with dynamic response behaviour
• This enclosure heater is designed for long-term use
• Quick to mount using clips for 35 mm DIN rail
Heating element: PTC resistor - temperature limiting
Heater body: extruded aluminium profile, anodised
Mounting: clip for 35mm DIN rail, EN 60715
Fitting position: vertical airflow (air outlet up, connection on bottom)
Operating/Storage temperature: -45 to +70 °C (-49 to +158 °F)
Operating/Storage humidity: < 90% RH (non-condensing)
Protection type/Protection class: IP44 / I (earthed)
Accessories: screw fixing, Art. No. 09024.0-00 (1 packing unit = 2 pieces)
Brand |
STEGO |
|
£28.53
per 1 (ex. VAT)£34.24
per 1 (inc. VAT)
ENCLOSURE HEATER
HGK 047 | 30 W
This compact enclosure heater with a PTC heating element prevents condensation in control cabinets. It is a convection heater for small control cabinets and enclosures. The heater body has an anodised aluminium profile.
• Wider range of voltages for electrical connection
• PTC heating element with dynamic response behaviour
• This enclosure heater is designed for long-term use
• Quick to mount using clips for 35 mm DIN rail
Heating element: PTC resistor - temperature limiting
Heater body: extruded aluminium profile, anodised
Mounting: clip for 35mm DIN rail, EN 60715
Fitting position: vertical airflow (air outlet up, connection on bottom)
Operating/Storage temperature: -45 to +70 °C (-49 to +158 °F)
Operating/Storage humidity: < 90% RH (non-condensing)
Protection type/Protection class: IP44 / I (earthed)
Accessories: screw fixing, Art. No. 09024.0-00 (1 packing unit = 2 pieces)
Brand |
STEGO |
|
