Part Number: 750-468/040-000
Manufacturer Code: 750-468/040-000
Multiples of: 1 | Minimum Order: 1
4-channel analog input; 0 ... 10 VDC; Single-ended; Extreme
This analog input module processes standard 0–10 V signals. The input signal is electrically isolated and is transmitted with a resolution of 12 bits. The internal system supply powers the module. The input channels of the module have a common ground potential. The shield directly connects to the DIN-rail.
The device is ideal for operation in extreme environments thanks to:
• An extended temperature range
• Greater immunity to impulse voltages and electromagnetic interference
• Higher vibration and shock resistance
Brand |
WAGO |
|
£330.20
per 1 (ex. VAT)£396.24
per 1 (inc. VAT)
4-channel analog input; 0 ... 10 VDC; Single-ended; Extreme
This analog input module processes standard 0–10 V signals. The input signal is electrically isolated and is transmitted with a resolution of 12 bits. The internal system supply powers the module. The input channels of the module have a common ground potential. The shield directly connects to the DIN-rail.
The device is ideal for operation in extreme environments thanks to:
• An extended temperature range
• Greater immunity to impulse voltages and electromagnetic interference
• Higher vibration and shock resistance
