My Part Number:
Part Number: 1732111
Manufacturer Code: ZFKDS1,SC-5,O-EX
Multiples of: 50 | Minimum Order: 50
PCB terminal block - ZFKDS 1,5C-5,0-EX
Nominal current: 16 A
Nominal cross section: 1.5 mm2
Number of potentials: 1
Number of rows: 1
Number of positions per row: 1
Product range: ZFKDS(A) 1,5C-EX
Pitch: 5 mm
Connection method: Spring-cage connection
Mounting: Wave soldering
Conductor/PCB connection direction: 45 °
Colour: green
Pin layout: Linear pinning
Solder pin [P]: 3.5 mm
Number of solder pins per potential: 2type of packaging:
Single module for the custom grouping of different numbers of positions. An end terminal block is also needed to terminate the block
Brand |
PHOENIX CONTACT |
|
£0.71
per 1 (ex. VAT)£0.85
per 1 (inc. VAT)
PCB terminal block - ZFKDS 1,5C-5,0-EX
Nominal current: 16 A
Nominal cross section: 1.5 mm2
Number of potentials: 1
Number of rows: 1
Number of positions per row: 1
Product range: ZFKDS(A) 1,5C-EX
Pitch: 5 mm
Connection method: Spring-cage connection
Mounting: Wave soldering
Conductor/PCB connection direction: 45 °
Colour: green
Pin layout: Linear pinning
Solder pin [P]: 3.5 mm
Number of solder pins per potential: 2type of packaging:
Single module for the custom grouping of different numbers of positions. An end terminal block is also needed to terminate the block
Brand |
PHOENIX CONTACT |
|
