My Part Number:
Part Number: 1757271
Manufacturer Code: MSTBA 2,5/ 5-G-5,08
Multiples of: 250 | Minimum Order: 250
PCB headers
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Well-known mounting principle allows worldwide use
Plug-in direction parallel to the PCB
Closed contour for optimum stability of the plug-in connection
Easy PCB replacement thanks to plug-in modules
Nominal current: 12 A
Number of positions: 5
Pitch: 5.08 mm
Contact surface: Tin
Mounting: Wave soldering
Brand |
PHOENIX CONTACT |
|
£1.11
per 1 (ex. VAT)£1.33
per 1 (inc. VAT)
PCB headers
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Well-known mounting principle allows worldwide use
Plug-in direction parallel to the PCB
Closed contour for optimum stability of the plug-in connection
Easy PCB replacement thanks to plug-in modules
Nominal current: 12 A
Number of positions: 5
Pitch: 5.08 mm
Contact surface: Tin
Mounting: Wave soldering
Brand |
PHOENIX CONTACT |
|
