My Part Number:
Part Number: 2313805
Manufacturer Code: PSI-WL-RS232-RS485/BT/2DO
Multiples of: 1 | Minimum Order: 1
Bluetooth converter, wireless transmission: RS-232/RS-422/RS-485 2-wire, mounting on EN DIN rails, MCX connection for external antenna, integrated path diagnostics: bar graph + two digital outputs
Local configuration via USB interface without separate power supply unit
Multipoint with up to seven slaves
Suitable for worldwide use thanks to adjustable transmission power (-28 ... 14 dBm)
Wireless path diagnostics using integrated bar graphs and 2 digital outputs
Secure and tamper-proof data transmission thanks to password protection, encryption, plus fixed and invisible device pairing
Coexistence with other wireless systems due to the adaptive frequency hopping (AFH) method
Can be used for RS-232/RS-422/RS-485 2-wire interfaces up to 187.5 kbps
Transceiver for distances of up to 150 m
Installation of parallel wireless paths by cross-wiring 24 V DC and RS-485
Brand |
PHOENIX CONTACT |
|
£641.10
per 1 (ex. VAT)£769.32
per 1 (inc. VAT)
Bluetooth converter, wireless transmission: RS-232/RS-422/RS-485 2-wire, mounting on EN DIN rails, MCX connection for external antenna, integrated path diagnostics: bar graph + two digital outputs
Local configuration via USB interface without separate power supply unit
Multipoint with up to seven slaves
Suitable for worldwide use thanks to adjustable transmission power (-28 ... 14 dBm)
Wireless path diagnostics using integrated bar graphs and 2 digital outputs
Secure and tamper-proof data transmission thanks to password protection, encryption, plus fixed and invisible device pairing
Coexistence with other wireless systems due to the adaptive frequency hopping (AFH) method
Can be used for RS-232/RS-422/RS-485 2-wire interfaces up to 187.5 kbps
Transceiver for distances of up to 150 m
Installation of parallel wireless paths by cross-wiring 24 V DC and RS-485
Brand |
PHOENIX CONTACT |
|
