My Part Number:
Part Number: 2700282
Manufacturer Code: AXL E IOL AO1 IM12 R
Multiples of: 1 | Minimum Order: 1
Axioline E-IO-Link/analog converter for connecting an analog actuator, 4 mA ... 20 mA, M12 fast connection technology, angled version
Angled version
1 IO-Link interface
1 analog output
Connection of the actuator in 3-wire technology
Current range: 4 mA ... 20 mA
IO-Link and actuator connections via M12 connectors
FE connection for local connection to functional earth ground
Supply of the module electronics and the actuator via the IO-Link interface of the IO-Link master
Diagnostic indicator
Brand |
PHOENIX CONTACT |
|
£171.11
per 1 (ex. VAT)£205.33
per 1 (inc. VAT)
Axioline E-IO-Link/analog converter for connecting an analog actuator, 4 mA ... 20 mA, M12 fast connection technology, angled version
Angled version
1 IO-Link interface
1 analog output
Connection of the actuator in 3-wire technology
Current range: 4 mA ... 20 mA
IO-Link and actuator connections via M12 connectors
FE connection for local connection to functional earth ground
Supply of the module electronics and the actuator via the IO-Link interface of the IO-Link master
Diagnostic indicator
Brand |
PHOENIX CONTACT |
|
