My Part Number:
Part Number: 2861328
Manufacturer Code: IB IL TEMP 2 RTD-PAC
Multiples of: 1 | Minimum Order: 1
Inline, Temperature measurement terminal, including Inline connector and labeling field
The terminal is designed for use within an Inline station.
It is used to acquire signals from resistive temperature sensors.
Two inputs for resistive temperature sensors
Pt, Ni, Cu, KTY sensor types according to DIN and SAMA
Connection of sensors in 2, 3, and 4-wire technology
The channels are parameterized independently of one another via the bus system
Measured values can be represented in three different formats
Measured value acquisition with 16-bit resolution
Analog RTD inputs: 2
Connection method: 2, 3, 4-wire
Transmission speed in the local bus: 500 kbps
Degree of protection: IP20
Brand |
PHOENIX CONTACT |
|
£283.69
per 1 (ex. VAT)£340.43
per 1 (inc. VAT)
