My Part Number:
Part Number: 2862246
Manufacturer Code: IL PB BK DP/V1-PAC
Multiples of: 1 | Minimum Order: 1
Inline, Bus coupler, PROFIBUS DP, D-SUB-9 female connector, transmission speed in the local bus: 500 kbps, degree of protection: IP20, including Inline connector and labeling field
PROFIBUS connection via 9-pos. D-SUB socket
PROFIBUS data transmission speed of 9.6 kbps to 12 Mbps
Electrical isolation between PROFIBUS interface and logic
DIP switch to set the PROFIBUS address
Supported PROFIBUS addresses from 0 to 126
DP/V1 for class 1 and class 2 masters
Brand |
PHOENIX CONTACT |
|
£273.88
per 1 (ex. VAT)£328.66
per 1 (inc. VAT)
