My Part Number:
Part Number: 2863944
Manufacturer Code: IB IL AI 2/SF-ME
Multiples of: 1 | Minimum Order: 1
Inline, Analog input terminal, including Inline connector and labeling field
The terminal is designed for use within an Inline station.
It is used to acquire analog voltage and current signals.
2 analog single-ended signal inputs for the connection of either voltage or current signals
Connection of sensors in 2-wire technology
Current ranges: 0 mA ... 20 mA, 4 mA ... 20 mA, ±20 mA
Voltage ranges: 0 V ... 10 V, ±10 V
Channels are parameterized independently of one another via the bus system
Measured values can be represented in four different formats
Resolution: 12 bits + sign bit
Process data update of both channels within a max. of 1.5 ms
Analog inputs: 2, 0 V ... 10 V, -10 V ... 10 V, 0 mA ... 20 mA, 4 mA ... 20 mA, -20 mA ... 20 mA
Connection method: 2-wire
Transmission speed in the local bus: 500 kbps
Degree of protection: IP20
Brand |
PHOENIX CONTACT |
|
£211.55
per 1 (ex. VAT)£253.86
per 1 (inc. VAT)
