My Part Number:
Part Number: 2864273
Manufacturer Code: MINI MCR-SL-PT100-UI-NC
Multiples of: 1 | Minimum Order: 1
MCR temperature transducer for Pt 100 temperature sensors, configured via DIP switch, with screw connection, not pre-configured.
Power supply possible via the foot element (TBUS)
For 2, 3 or 4-wire Pt 100 sensors according to IEC 60751
Error indication via diagnostic LED and analog signal
Input and output signals can be configured via DIP switches
Highly-compact temperature transducer for electrical isolation, conversion, amplification, and filtering
3-way isolation
Pt 100 signals to create standard signals
Temperature measuring range of -150°C to +850°C
Brand |
PHOENIX CONTACT |
|
£220.01
per 1 (ex. VAT)£264.01
per 1 (inc. VAT)
MCR temperature transducer for Pt 100 temperature sensors, configured via DIP switch, with screw connection, not pre-configured.
Power supply possible via the foot element (TBUS)
For 2, 3 or 4-wire Pt 100 sensors according to IEC 60751
Error indication via diagnostic LED and analog signal
Input and output signals can be configured via DIP switches
Highly-compact temperature transducer for electrical isolation, conversion, amplification, and filtering
3-way isolation
Pt 100 signals to create standard signals
Temperature measuring range of -150°C to +850°C
Brand |
PHOENIX CONTACT |
|
