My Part Number:
Part Number: 2864299
Manufacturer Code: MINI MCR-SL-TC-UI-NC
Multiples of: 1 | Minimum Order: 1
MCR temperature transducer for thermocouples, can be configured via DIP switches, with screw connection, standard configuration.
Power supply possible via the foot element (TBUS)
For J and K thermocouples according to IEC 60584
Error indication via diagnostic LED and analog signal
Temperature measuring range of -150°C to +1350°C
Highly-compact temperature transducer for electrical isolation, conversion, amplification, and filtering of thermocouple signals to create standard signals
Internal cold junction compensation
Input and output signals can be configured via DIP switches
3-way isolation
Brand |
PHOENIX CONTACT |
|
£152.30
per 1 (ex. VAT)£182.76
per 1 (inc. VAT)
MCR temperature transducer for thermocouples, can be configured via DIP switches, with screw connection, standard configuration.
Power supply possible via the foot element (TBUS)
For J and K thermocouples according to IEC 60584
Error indication via diagnostic LED and analog signal
Temperature measuring range of -150°C to +1350°C
Highly-compact temperature transducer for electrical isolation, conversion, amplification, and filtering of thermocouple signals to create standard signals
Internal cold junction compensation
Input and output signals can be configured via DIP switches
3-way isolation
