My Part Number:
Part Number: 750-315/300-000
Manufacturer Code: 750-315/300-000
Multiples of: 1 | Minimum Order: 1
Fieldbus Coupler MODBUS - RS-485, 115,2 kBd, light gray
This fieldbus coupler connects the WAGO I/O System as a slave to the MODBUS fieldbus. The fieldbus coupler detects all connected I/O modules and creates a local process image. Analog and specialty module data is sent via words and/or bytes, digital data is sent bit by bit.
The data of the analog modules is stored in the process image that is created automatically according to the order in which the modules are connected to the coupler. The bits of the digital modules are sent byte by byte and added to the analog data. If the amount of digital I/O information exceeds eight bits, the coupler automatically starts with a new byte.
Connection technology: communication/fieldbus: Modbus® RTU: 1 x D-sub 9 socket
Connection technology: field supply: 6 x CAGE CLAMP®
Connection technology: system supply: 2 x CAGE CLAMP®
Connection technology: device configuration: 1 x Male connector; 4-pole
Connection type 1: System/field supply
Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
Strip length: 8 … 9 mm / 0.31 … 0.35 inches
Width: 50.5 mm / 1.988 inches
Height: 100 mm / 3.937 inches
Depth: 71.1 mm / 2.799 inches
Mounting type: DIN-35 rail
Housing material: Polycarbonate; polyamide 6.6
Brand |
WAGO |
|
£418.99
per 1 (ex. VAT)£502.79
per 1 (inc. VAT)
